CBW-1200 Pipeline Booster Piston Pump

The CBW-1200 Pipeline booster pump is a horizontal triplex reciprocating single-acting piston pump featuring five-stage flow regulation.

This equipment significantly enhances wear resistance and pressure tolerance, enabling long-term stable operation under diverse complex water conditions and high-temperature environments. Its unique triplex structure employs progressive pressure boosting to ensure smoother pressure output during liquid transfer, substantially reducing pipeline vibration and noise caused by pressure fluctuations. Additionally, the unit incorporates an intelligent pressure sensing control system that continuously monitors pipeline pressure changes. It automatically starts/stops or adjusts operating power based on preset thresholds, achieving high energy efficiency while preventing potential damage to the pump body and pipeline system caused by overpressure operation.

In practical applications, this equipment flexibly adapts to pipeline systems of varying diameters and features simple, rapid installation. It enables efficient deployment in both new construction projects and retrofitting of existing pipelines.

Features

1. Powerful pressure output: Featuring a reciprocating piston design, the alternating motion of the piston within the cylinder creates volumetric changes to generate high output pressure. This meets the demands of high-pressure applications such as high pressure cleaning, oilfield water injection, and mining grouting.

2. Stable Flow: Benefiting from a unique single-acting piston operation mode, it delivers uniform and continuous liquid flow without pulsation. This makes it particularly suitable for applications demanding high flow stability, such as precision chemical reactions.

3. Precise Adjustment: Features multi-stage flow regulation. Flow can be precisely controlled by altering piston stroke or adjusting rotational speed. Its wide adjustment range allows flexible adaptation to varying flow requirements across different process stages.

4. Wear and Corrosion Resistance: Critical flow components like cylinders and pistons are crafted from high-hardness alloy or ceramic materials with specialized surface treatments. This delivers outstanding wear and corrosion resistance, effectively withstanding erosion from sandy water or acidic media to extend equipment lifespan.

5. Reliable operation: The transmission system employs high-precision gear meshing paired with premium bearings to ensure efficient and stable power transfer with low failure rates. Additionally, the equipment features a comprehensive lubrication system that thoroughly lubricates all moving parts, reducing friction loss and ensuring long-term continuous operation.

Technical Parameters and Specifications

Advantages

The pipeline booster pump offers significant advantages. Equipped with an intelligent pressure sensing control system, it continuously monitors pipeline pressure and automatically adjusts operation to achieve high efficiency and energy savings while preventing overpressure damage. Powered by a reliable Cummins diesel engine, its compact and space-saving design ensures long-term stable operation through premium materials and precision craftsmanship. Simple operation and dependable performance allow quick mastery even without specialized expertise, maintaining stable and efficient operation in complex environments. The easy-disassembly design simplifies routine maintenance and relocation, significantly reducing time and labor costs. Flexible adaptability to various pipe diameters enables efficient installation and deployment, making it suitable for both new construction projects and retrofitting existing pipelines.
